دستگاه پرس ولکانیزه لاستیکی
>
High-efficiency 3RT Semi-automatic Rubber Vulcanizing Press with 400mm Stroke and 600×600mm Plate Size

High-efficiency 3RT Semi-automatic Rubber Vulcanizing Press with 400mm Stroke and 600×600mm Plate Size

نام تجاری: Beishun
شماره مدل: XLB-600×600/1.0MN
مقدار تولیدی: 1 مجموعه
قیمت: قابل مذاکره
جزئیات بسته بندی: جعبه چوبی/20GP/40GP
شرایط پرداخت: T/T، L/C
اطلاعات دقیق
محل منبع:
qingdao
گواهی:
ISO/CE
روش گرمایشی:
برق، روغن حرارتی یا بخار
خدمات سفارشی:
پشتیبانی از سفارشی سازی
روش باز کردن قالب:
دستی/اتوماتیک
سکته:
400 میلی متر
اندازه بشقاب:
600 × 600 میلی متر یا به عنوان نیاز شما
حالت کنترل:
خودکار
پیستون:
آهن ریخته سرد HS 72-75 سخت
روش گرم کردن:
گرمایش برق
محدوده دما:
0-200
تضمین کیفیت:
5 سال
مشخصات:
سفارشی
لایه کار:
1-4 لایه
زمان ولکانیزاسیون:
0-999S
قابلیت ارائه:
30 ثانیه
برجسته کردن:

3RT Rubber Vulcanizing Press,400mm Stroke Vulcanizing Press,600×600mm Plate Vulcanizing Press

,

400mm Stroke Vulcanizing Press

,

600×600mm Plate Vulcanizing Press

توضیحات محصول
High-efficiency Semi-automatic 3RT Rubber Vulcanizing Press for Rubber Handle Production
This specialized hydraulic press is designed for molding and curing (vulcanizing) rubber compounds to produce high-quality rubber handles with consistent results.
Machine Overview
The 3RT designation refers to the press's Three-Rod, Two-Platen frame configuration that ensures precise parallel movement for consistent product quality.
Key Features
  • Semi-automatic operation balances productivity and control
  • High-efficiency design with fast cycles and precise controls
  • Robust three-rod construction for durability
  • Energy-efficient systems reduce operating costs
Production Process
The vulcanization process transforms raw rubber into durable finished handles through controlled heat and pressure application:
Step-by-Step Operation
  1. Preparation: Clean mold and load precise rubber amount
  2. Cycle Initiation: Operator starts automated process
  3. Mold Closing: Platens bring mold halves together
  4. Vulcanization: Controlled heat (150°C-200°C) and pressure (150-300 kg/cm²) applied
  5. Demolding: Automatic press opening for part removal
  6. Post-Processing: Trimming, inspection, and cooling
Production Advantages
  • Consistent quality with uniform wall thickness
  • High productivity with semi-automatic operation
  • Reduced labor requirements and skill dependency
  • Energy-efficient operation lowers costs
  • Durable construction ensures long service life
  • Flexible production with interchangeable molds
Typical Applications
The rubber handles produced are ideal for applications requiring comfortable, non-slip grips:
  • Hand tools (pliers, screwdrivers, hammers)
  • Kitchen utensils (knives, pot handles)
  • Sports equipment (golf clubs, rackets)
  • Industrial controls (valves, levers)
  • Garden tools (pruners, shears)
High-efficiency 3RT Semi-automatic Rubber Vulcanizing Press with 400mm Stroke and 600×600mm Plate Size 0 High-efficiency 3RT Semi-automatic Rubber Vulcanizing Press with 400mm Stroke and 600×600mm Plate Size 1
