دستگاه پرس ولکانیزه لاستیکی

High Thermal Efficiency Two-layer Frame Plate Vulcanizing Machine - Used To Manufacture Rubber Fiberboard

تمام دسته ها

ماشین خنک کننده لاستیکی دسته ای

دستگاه ولکانیزاسیون تسمه نقاله

قطعات ماشین لاستیکی

با ما تماس بگیرید

Mr. Alexey Pan

info@beishunchina.com

0086 15154222850

اکنون تماس بگیرید

High Thermal Efficiency Two-layer Frame Plate Vulcanizing Machine - Used To Manufacture Rubber Fiberboard

نام تجاری:	Beishun
شماره مدل:	XBL-1000*1000/5.00MN
مقدار تولیدی:	1SET
قیمت:	قابل مذاکره
شرایط پرداخت:	T/T، L/C

اطلاعات دقیق

توضیحات محصول

اطلاعات دقیق

محل منبع:

چینگدائو، چین

گواهی:

ISO/CE/SGS

منبع برق:

سفارشی سازی

راه گرمایش:

حرارت الکتریکی / بخار

حداکثر اندازه محصول:

1000x1000 میلی متر

Pressure Range:

16.8(mpa)

منبع برق:

شکاف صفحات:

۳۰۰ میلی متر

5000 کیلوگرم

Type:

hydraulic

مقدار صفحه Vulcanizing:

مواد پیستون:

چدن سرد شده

ساختار:

نوع ستون

سبک ساختار:

میتوشیبی، زیمنس.

Cylinder Stroke:

200mm

قدرت:

15 کیلو وات

قابلیت ارائه:

30 مجموعه در ماه

توضیحات محصول

High Thermal Efficiency Two-layer Frame Plate Vulcanizing Machine - Used To Manufacture Rubber Fiberboard

Machine introduction:

1. Types of rubber fiber sheet vulcanizers

(1) Flat vulcanizer (intermittent vulcanization)
Applicable products:

Ordinary rubber sheets (such as anti-slip mats, industrial rubber sheets)

Insulating rubber sheets (for distribution rooms)

Oil-resistant, acid-resistant and alkali-resistant rubber sheets

Conductive/antistatic rubber sheets

Composite rubber sheets with fiber reinforcement layers (such as asbestos rubber sheets, canvas-reinforced rubber sheets)

Working principle:

Put the mixed rubber sheet (or fiber-reinforced rubber composite material) into the mold.

High pressure (usually 10-20MPa) is applied through the hydraulic system, and the heating plate provides temperature (140-180℃).

Maintain a certain time (5-30 minutes, depending on the thickness) to complete the vulcanization.

Equipment features:

Can produce a wide range of thicknesses (1mm~50mm).

Suitable for small batch and multi-specification production.

Multi-layer vulcanization table can be added (to improve efficiency).

Technical Parameters

Parameter	Typical Range	Explanation
Temperature	140 - 180°C	For Natural Rubber (NR), it is usually 150 - 160°C. For EPDM, it can reach 170 - 180°C.
Pressure	10 - 20MPa	To ensure the rubber flows adequately and eliminate air bubbles.
Vulcanization Time	5 - 30 minutes	Depends on the thickness (e.g., for 5mm thickness, it takes about 10 - 15 minutes).
Cooling Method	Natural cooling / Water cooling	To prevent deformation and improve dimensional stability.

High Thermal Efficiency Two-layer Frame Plate Vulcanizing Machine - Used To Manufacture Rubber Fiberboard 0

3. Special requirements for fiber-reinforced rubber sheets
If the rubber sheet contains a fiber-reinforced layer (such as canvas, nylon, polyester fiber or asbestos fiber), pay attention to the following during vulcanization:

Fiber pretreatment: Glue or dip is required to improve adhesion with rubber.

Vulcanization pressure: Higher pressure (15-25MPa) is required to ensure that the rubber penetrates the fiber layer.

Temperature control: Avoid excessively high temperatures that may cause fiber aging (such as nylon fiber temperature resistance ≤180℃).

4. Common Problems and Solutions

Problem	Possible Causes	Solutions
Bubbles/Layering	Insufficient pressure, poor venting	Increase pressure, add venting grooves to the mold
Uneven thickness	Uneven mold, poor fluidity of rubber compound	Adjust the parallelism of the mold, optimize the rubber compound formula
Delamination between fiber and rubber	Untreated fiber or insufficient adhesion	Pre - coat fiber with adhesive, increase vulcanization pressure
Rough surface	Mold contamination, uneven temperature	Clean the mold, check the temperature uniformity of the heating plate

High Thermal Efficiency Two-layer Frame Plate Vulcanizing Machine - Used To Manufacture Rubber Fiberboard 2
